The chart below shows the energy production for four photovoltaic (PV) arrays at the Boston Nature Center. The four installations demonstrate that PV arrays can be roof shingles, pole-mounted, roof-mounted, and ground-mounted.
Hover over the graph with your mouse or click on any day for more detail. Choose a different date range with the buttons at the top right of the graph.
Learn more about these arrays >
|
|
|
PV Roof ShinglesThe George Robert White Environmental Conservation Center has 2.7 kW photovoltaic shingles installed on the southern side of the roof's cupola which convert the sun's energy into electricity.
|
|
|
|
|
|
Pole-Mounted ArraysBehind the Environmental Conservation Center, there are 9.8 kW photovoltaic pole mounted solar arrays.
|
|
|
|
|
|
Roof-Mounted ArraysLocated on Boston Nature Center's garage are 12.15 kW photovoltaic roof mounted arrays.
|
|
|
|
|
|
Ground-Mounted ArraysAdjacent to Boston Nature Center's garage are 5.3 kW photovoltaic ground mounted arrays.
|
|
|
